CF 18801 TRANSDUCTOR STM ELECTRONICS 18″

STM ELECTRONICS 10ND-75 GENERAL SPECIFICATIONS SMALL SIGNAL PARAMETERS Nominal diameter 260mm/10 in Power rating 300-600W Nominal impedance 8 ohms Sensitivity 96 dB Frequency range 65-3500Hz Chassis type Cast aluminium Magnet type Neodymium Magnet Size 74X15X10 mm Magnet weight 0.32kg/11.30z Voice coil diameter 75.5mm/3in Coil material SV-W Number of layers 2 (outside) Former material Glass fiber Cone material Paper Surround material Cloth Spider Simmo,19in X-max 5mm Gap depth 15mm Sin Voice coil winding width 15mm Net Weight 3.5 kg/pc Packing Dimension W x D x H(mm) 545mmX275mmX320mm
